Flanges
Weld Neck, Slip-On, Blind, Socket Weld & Threaded Flanges — a full range of forged carbon steel and stainless steel flanges to ASME/ANSI and EN standards, covering all common pressure classes.
Overview
150# to 2500#, forged to ASME & EN standards.
We supply a full range of forged carbon steel and stainless steel flanges to ASME/ANSI and EN standards, covering all common pressure classes for pipeline and process piping connections.
| Product Type | Standard / Grade | Pressure Class | Size Range |
|---|---|---|---|
| Weld Neck Flanges | ASTM A105 / A182 F304, F316 | 150# – 2500# | 1/2″ – 24″ |
| Slip-On Flanges | ASTM A105 / A182 F304, F316 | 150# – 1500# | 1/2″ – 24″ |
| Blind Flanges | ASTM A105 / A182 F304, F316 | 150# – 2500# | 1/2″ – 24″ |
| Socket Weld Flanges | ASTM A105 / A182 F304, F316 | 150# – 1500# | 1/2″ – 4″ |
| Threaded Flanges | ASTM A105 | 150# – 300# | 1/2″ – 4″ |
| Lap Joint Flanges | ASTM A105 / A182 F304, F316 | 150# – 1500# | 1/2″ – 24″ |
EN 1092-1 (DIN) flanges also available on request.
Applications
Pipeline and process piping connections, equipment and valve interfaces, and flanged joints requiring bolted, pressure-rated seals.
Need a Specific Pressure Class?
Request flange availability & mill test certification.
