European Wide Flange Beams (HE)
Hot-rolled European wide flange beams (HEA / HEB / HEM series) to EN 10025-2, offering a broad range of section weights per depth for varying load requirements.
Overview
HE100 to HE1000, heavy sections for high-rise and bridge frames.
Hot-rolled European wide flange beams (HEA / HEB / HEM series) to EN 10025-2, offering a broad range of section weights per depth for varying load requirements. Exact mass per metre depends on the A (light), B (medium) or M (heavy) sub-series — full breakdown available in our catalogue.
| Series | Standard | Depth Range | Weight Range | Typical Grade |
|---|---|---|---|---|
| HE100 (A/B/M) | EN 10025-2 | 96 – 120 mm | 17 – 41 kg/m | S235 / S275 / S355 |
| HE200 (A/B/M) | EN 10025-2 | 190 – 220 mm | 42 – 103 kg/m | S235 / S275 / S355 |
| HE300 (A/B/M) | EN 10025-2 | 290 – 340 mm | 88 – 238 kg/m | S235 / S275 / S355 |
| HE500 (A/B/M) | EN 10025-2 | 490 – 524 mm | 155 – 445 kg/m | S235 / S275 / S355 |
| HE700 (A/B/M) | EN 10025-2 | 690 – 716 mm | 204 – 723 kg/m | S235 / S275 / S355 |
| HE1000 (A/B/M) | EN 10025-2 | 936 – 1008 mm | 272 – 1063 kg/m | S235 / S275 / S355 |
Note: exact mass per metre depends on the A (light), B (medium) or M (heavy) sub-series — full breakdown available in our catalogue. Other sizes and grades available on request.
Applications
Heavy structural columns and beams for industrial buildings, high-rise frames, and bridges.
Need Full Dimensions?
Request the full HE designation & dimension table.
